sh15-m非晶合金变压器
sh15-m非晶合金变压器技术参数表：
|
额定容量
kva
|
电压组合
|
联结组标号
|
空载损耗.
w
|
负载损耗
w
|
空载电流
%
|
短路阻抗
%
|
外形尺寸（mm）
l xw x h
|
重量
kg
|
安装尺寸
（mm）
|
|
高压kv
|
高压分接范围
%
|
低压kv
|
|
sh15-30
|
6
6.3
10
10.5
11
|
±5%
or
±2x
2.5%
|
0.4
|
yyn0
or
dyn11
|
33
|
600
|
1.7
|
4
|
1080x600x1060
|
660
|
400x400
|
|
sh15-50
|
43
|
870
|
1.3
|
4
|
1090x600x1070
|
700
|
400x450
|
|
sh15-63
|
50
|
1040
|
1.2
|
4
|
1110x650x1080
|
765
|
400x450
|
|
sh15-80
|
60
|
1250
|
1.1
|
4
|
1130x650x1100
|
820
|
400x450
|
|
sh15-100
|
75
|
1500
|
1.0
|
4
|
1150x650x1120
|
865
|
550x660
|
|
sh15-125
|
85
|
1800
|
0.9
|
4
|
1170x650x1180
|
930
|
550x660
|
|
sh15-160
|
100
|
2200
|
0.7
|
4
|
1200x650x1200
|
1029
|
550x870
|
|
sh15-200
|
120
|
2600
|
0.7
|
4
|
1230x650x1220
|
1170
|
550x870
|
|
sh15-250
|
140
|
3050
|
0.7
|
4
|
1260x850x1260
|
1320
|
660x870
|
|
sh15-315
|
170
|
3650
|
0.5
|
4
|
1270x1120x1285
|
1490
|
660x870
|
|
sh15-400
|
200
|
4300
|
0.5
|
4
|
1310x1120x1425
|
1730
|
660x1070
|
|
sh15-500
|
240
|
5150
|
0.5
|
4
|
1420x1120x1305
|
1950
|
660x1070
|
|
sh15-630
|
320
|
6200
|
0.3
|
4.5
|
1490x1120x1315
|
2280
|
820x1070
|
|
sh15-800
|
380
|
7500
|
0.3
|
4.5
|
1575x1120x1520
|
2750
|
820x1070
|
|
sh15-1000
|
450
|
10300
|
0.3
|
4.5
|
1640x1120x1570
|
3322
|
820x1070
|
|
sh15-1250
|
530
|
12000
|
0.2
|
4.5
|
1690x1300x1600
|
2750
|
820x1070
|
|
sh15-1600
|
630
|
14500
|
0.2
|
4.5
|
1820x1350x1695
|
3950
|
820x1070
|
注：外形尺寸仅供参考，以产品图纸为准。
|
